Advanced Ideas for Rigorous
Moulding Requirements
FEED SYSTEM
The Infeed Rolls work in conjunction with a limit switch
to stop the machine if workpiece is too thick or there is
a double up.
CONVENIENT SPINDLE ADJUSTMENT
Adjustment of all spindles is easily effected from the
front of the moulder. The adjustment points are all at
the same height, for more convenient and faster
adjustment.
CENTRALIZED LUBRICATION POINTS
Greasing to all critical parts is conveniently made by the
centralized arrangement of color coded lubrication
points along the front of the machine.
HIGH PRECISION SPINDLES
All spindles are precision constructed and specially
heat treated to provide maximum cutting stability and
permanent accuracy. 4 Super Precision Bearings per
Spindle provide the best most accurate spindles
available.
They are water and dust-proof. Standard spindle speed
is 6,000 RPM and 7,200 or 8,000 RPM are optional.
PNEUMATICALLY PRESSURED SIDE PRESSURE
ROLLS OPPOSITE 2ND REAR SIDE HEAD SPINDLE
Provides positive feed effect for all types of material &
short and narrow stock.
09 / 10
HYPERMAC series
LEADERMAC
HEAVY SIDE PRESSURE WHEELS FOR LEFT VERTICAL
SPINDLE (OPT.)
Eliminating the conventional spindle load, the adjustable side
pressure wheels for the left vertical spindle are pneumatically
operated to ensure consistent holding pressure.
TWO TOP & TWO BOTTOM INFEED ROLLERS (OPT.)
• The smooth initial feeding of the stock is achieved by means
of the independently powered infeed rollers.
• There are more top and bottom powered rollers than in
most competitor’s models, and this is an important reason
for outstanding feeding performance.
