A Wide Range of
Spindle Configurations
- Machines of 2 to 11 Heads are
available with almost any
configuration of heads as desired
A sampling of some Standard Head
configurations -
LEADERMAC's wide variety of 4-side
moulders have all the very latest
technology for increased productivity,
product quality & reliability. These Heavy
Duty Moulders are designed to provide
fast cutting speeds and highest quality
& accuracy. These machines are preci-
sion manufactured by our highly skilled
technicians - plus Leadermac service,
training, and moulding know-how is
offered with each moulder. No matter
what your moulding jobs call for, there
is a Leadermac 4-side moulder that's
right for you.
L M C - 7 2 3
7 - SP INDLE
L M C - 6 2 3
6 - SP INDLE
L M C - 5 2 3
5 - SP INDLE
L M C - 4 2 3
4 - SP INDLE
L M C - 9 2 3
9 - SP INDLE
L M C - 8 2 3
8 - SP INDLE
STANDARD EQUIPMENT:
2 to 11
15~230mm (0.59"-9")
10~150mm (0.39"-6")
7.5 / 11KW (10 / 15HP)
40mm
6000 RPM
125~180mm (4.9"-7.1")
125~232mm (4.9"-9.1")
125~225mm (4.9"-8.8")
5.5KW / 7.5HP / INVERTER
6-36 m/min (20 / 120fpm)
140mm (5.5")
50mm (2") / Roll
Full Width
6 bar (85psi)
10mm (0.4")
80mm (3.2")
40mm (1.6")
2M (78")
Ø150mm (5.9")
Std.
Std.
Std.
Std.
Std.
Std.
Std.
Any Head Configuration - available
to 310mm(12.2"), 330mm (13")
to 200 (8")
to 37.5KW / 50HP
50mm, 1 13/16" / 2 1/8"
7200 / 8000 RPM
250mm / 9.8"
250mm / 9.8"
7.5 / 11 / 15KW (10 / 15 / 20HP) / INVERTER
48m/min (160fpm)
100mm / 4"
0.8 / 1.4 / 2.5 / 3M (32" / 55" / 98" / 120")
LMC-223H to LMC1123H Available Options
Number of Heads / Spindles, min-max
Working Width (with a tool cutting circle of 163mm)
Working Thickness (with a tool cutting circle of 163mm)
Basic Spindle Motor capacity
Spindle Diameter
Spindle Speed
Tool cutting circle, First Bottom Spindle, min-max
Tool cutting circle, Vertical Spindles, min-max
Tool cutting circle, Horizontal Spindles, min-max
Feed Motor
Feed speed, infinitely variable by frequency (VFD) driven
Top Feed Rolls - Diameter
Top Feed Roll Width - Multiple Rolls Stacked on shafts
Bottom Feed Roll Width
Pneumatic pressure for feed rollers, max
Adjustment range for Infeed Table(Btm Head Cut) and Edge Jointing Fence
Adjustment range of vertical spindles (axial)
Adjustment range of horizontal spindles (axial)
Length of the Infeed / Straightening table
Diameter of Dust Hoods for Vertical & Horizontal Spindles
Digital Readouts on All Axis of all Heads
Digital Readouts for the Pressure Shoes
Full Sound and Safety Enclosure w/ Strobe Free Lighting
Motorized vertical adjustment of Feed Beam
Lateral Pressure Multiple Roller opposite first right spindle
Chainless Cardan Shaft Feed System
REC Setworks on Near Side Head(s) & Top(s) - Radial
Tilting Top Beam, Tilting Feed, Tilting Feedworks, Tilting top Head Chipbreaker Ass'y,
Tilting Pressure Plate(s)
Tilting Side Heads
Grooved Bed for running very short material
Split Pressure Shoes
OPTIONAL EQUIPMENT:
Opposed Side Heads
Universal Spindle, tool cutting circle min 125mm, max 200mm
Rip Saw Section with up to 56kw (75HP)
Left (Opposite) Hand Feed
Inverter Motor Cutterhead Brakes
●
